Waveshare ESP32-S3-Touch-LCD-4.3C

Device Type:

Electrical Standard:

Board:

Difficulty:Plug-n-flash (2/5)

Waveshare ESP32-S3-RLCD-4.2 Front

Waveshare ESP32-S3-Touch-LCD-4.3C

ESP32-S3-Touch-LCD-4.3C

A small self-contained 4.3” widescreen display available in a plastic case. Basic video/audio/microphone capabilites.

The user can elect to install an internal battery.

The LEDs on the side of the hardware are indicators for the battery and cannot be controlled via ESPhome.

The on/off switch cuts power to the battery, otherwise has no affect if unit is hardwired.

Reset button restarts the device. The boot button is useful during initial installation of ESPhome.

Hardware Specifications

Feature	Spec
CPU	ESP32-S3-WROOM-1-N16R8
Flash	16MB
PSRAM	8MB
Screen	800*480 RGB LCD
Touch	GT911
Audio	ES8311
Microphone	ES7210
Time	PCF85063
Storage	TF Card Slot
IO Expander	CH32V003

Installation

Hold the reset button while connecting the USB-C cable. Then install ESPhome via standard browser method.

Basic Configuration

The following implements all hardware except the TF card slot and was built on esphome 2026.5.1.

The CH32V003 IO expander requests an external component found here .

In this config, the display will turn off after 60s idle. If display is off, touch will turn the display back on.

Some optimizations in esphome and esp32 compoments are set to increase the FPS performance.

https://github.com/esphome/esphome-devices/blob/main/src/docs/devices/waveshare-esp32-s3-touch-lcd-43c/config.yaml

################################################################################
# ESP32-S3-Touch-LCD-4.3C  —  ESPHome 2026.5.x
# Waveshare ESP32-S3-WROOM-1-N16R8 · 800×480 RGB LCD · GT911 touch
# ES8311 DAC · ES7210 ADC · PCF85063 RTC · Isolated I/O (DI0/DI1, DO0/DO1)
#
# IO Expander: CH32V003 RISC-V MCU at I²C 0x24 (GPIO8 SDA, GPIO9 SCL)
#   EXIO0  → DI0        (optocoupler digital input 0)
#   EXIO1  → CTP_RST    (GT911 touch reset)
#   EXIO2  → DISP       (LCD backlight enable — on/off)
#   EXIO3  → PA_CTRL    (NS4150B power amp enable)
#   EXIO4  → SDCS       (SD card chip select)
#   EXIO5  → DI1        (optocoupler digital input 1)
#   EXIO6  → DO0        (optocoupler digital output 0)
#   EXIO7  → DO1        (optocoupler digital output 1)
#   EXIO_PWM → BL_PWM   (backlight PWM brightness, inverted)
#   EXIO_ADC → VBAT sense (battery voltage via 10K/20K divider → ×3 ref)
################################################################################

globals:
  - id: screen_on
    type: bool
    restore_value: false
    initial_value: "true"

esphome:
  name: display
  friendly_name: Display
  platformio_options:
    build_flags:
      - "-D LV_USE_OBSERVER=1"
      # Enable when performance tuning
      # - "-D LV_USE_SYSMON=1"
      # - "-D LV_USE_PERF_MONITOR=1"
      # - "-D LV_USE_MEM_MONITOR=1"
      # - "-D LV_PERF_MONITOR_ALIGN_BOTTOM_RIGHT=1"
      # - "-D LV_MEM_MONITOR_ALIGN_BOTTOM_LEFT=1"
  on_boot:
    priority: 600
    then:
      - light.turn_on:
          id: backlight
          brightness: 80%
      - switch.turn_on: pa_ctrl

esp32:
  board: esp32-s3-devkitc-1
  variant: esp32s3
  flash_size: 16MB
  cpu_frequency: 240MHz
  framework:
    type: esp-idf
    sdkconfig_options:
      CONFIG_ESP32S3_DATA_CACHE_64KB: "y"
      CONFIG_ESP32S3_INSTRUCTION_CACHE_32KB: "y"
      CONFIG_SPIRAM_USE_MALLOC: "y"
      CONFIG_SPIRAM_MALLOC_ALWAYSINTERNALLY: "y"
      CONFIG_HEAP_TLSF_USE_ROM_IMPL: "y"
      CONFIG_HEAP_CORRUPTION_DETECTION: "basic"
      CONFIG_LV_MEMCPY_MEMSET_STD: "y"
      CONFIG_ESP_MAIN_TASK_AFFINITY_CPU1: "y"
    advanced:
      compiler_optimization: PERF
      execute_from_psram: true

psram:
  mode: octal
  speed: 80MHz

# External component for CH32V003 IO expander

external_components:
  - source:
      type: git
      url: https://github.com/fuzzybear62/esphome-waveshare_io_ch32v003
      ref: main
    components: [waveshare_io_ch32v003]

logger:
  level: DEBUG

wifi:
  ap:

i2c:
  sda: GPIO8
  scl: GPIO9
  scan: true
  id: bus_a

waveshare_io_ch32v003:
  id: waveshare_io_hub
  i2c_id: bus_a
  address: 0x24

display:
  - platform: mipi_rgb
    model: RPI
    id: lcd_display
    auto_clear_enabled: false
    update_interval: never
    color_order: RGB
    pclk_frequency: 20MHz  # Adjust downward if screen jitters
    pclk_inverted: true
    dimensions:
      width: 800
      height: 480
    de_pin: GPIO5
    hsync_pin:
      number: GPIO46
      ignore_strapping_warning: true
    vsync_pin:
      number: GPIO3
      ignore_strapping_warning: true
    pclk_pin: GPIO7
    hsync_back_porch: 30
    hsync_front_porch: 210
    hsync_pulse_width: 30
    vsync_back_porch: 4
    vsync_front_porch: 4
    vsync_pulse_width: 4
    data_pins:
      red:
        - GPIO1    # R3
        - GPIO2    # R4
        - GPIO42   # R5
        - GPIO41   # R6
        - GPIO40   # R7
      green:
        - GPIO39   # G2
        - GPIO0    # G3
        - GPIO45   # G4
        - GPIO48   # G5
        - GPIO47   # G6
        - GPIO21   # G7
      blue:
        - GPIO14   # B3
        - GPIO38   # B4
        - GPIO18   # B5
        - GPIO17   # B6
        - GPIO10   # B7

output:
  - platform: waveshare_io_ch32v003
    id: backlight_pwm_output
    waveshare_io_ch32v003_id: waveshare_io_hub
    inverted: true
    zero_means_zero: true
    safe_pwm_levels:
      min_value: 0
      max_value: 247

light:
  - platform: monochromatic
    id: backlight
    name: "Display Backlight"
    output: backlight_pwm_output
    restore_mode: RESTORE_AND_ON
    default_transition_length: 200ms

touchscreen:
  - platform: gt911
    id: touch_panel
    interrupt_pin: GPIO4
    reset_pin:
      waveshare_io_ch32v003: waveshare_io_hub
      number: 1        # EXIO1 = CTP_RST
      mode: OUTPUT
    on_touch:
      - light.turn_on:
          id: backlight
          brightness: 80%
      - switch.turn_on: disp_enable
      - lvgl.resume:

time:
  - platform: pcf85063
    id: rtc_time
    i2c_id: bus_a
    address: 0x51
    update_interval: 60s
    on_time_sync:
      then:
        - logger.log: "RTC time synced"

binary_sensor:
  - platform: gpio
    id: di0
    name: "Digital Input 0"
    pin:
      waveshare_io_ch32v003: waveshare_io_hub
      number: 0        # EXIO0 = DI0
      mode: INPUT
      inverted: true
    filters:
      - delayed_on: 20ms
      - delayed_off: 20ms
    device_class: connectivity

  - platform: gpio
    id: di1
    name: "Digital Input 1"
    pin:
      waveshare_io_ch32v003: waveshare_io_hub
      number: 5        # EXIO5 = DI1
      mode: INPUT
      inverted: true
    filters:
      - delayed_on: 20ms
      - delayed_off: 20ms
    device_class: connectivity

  - platform: status
    name: "Device Status"

switch:
  - platform: gpio
    id: do0
    name: "Digital Output 0"
    pin:
      waveshare_io_ch32v003: waveshare_io_hub
      number: 6        # EXIO6 = DO0
      mode: OUTPUT
    restore_mode: ALWAYS_OFF

  - platform: gpio
    id: do1
    name: "Digital Output 1"
    pin:
      waveshare_io_ch32v003: waveshare_io_hub
      number: 7        # EXIO7 = DO1
      mode: OUTPUT
    restore_mode: ALWAYS_OFF

  - platform: gpio
    id: pa_ctrl
    name: "Speaker"
    internal: false
    pin:
      waveshare_io_ch32v003: waveshare_io_hub
      number: 3        # EXIO3 = PA_CTRL
      mode: OUTPUT
    restore_mode: ALWAYS_OFF

  - platform: gpio
    id: disp_enable
    name: "Display"
    internal: true
    pin:
      waveshare_io_ch32v003: waveshare_io_hub
      number: 2        # EXIO2 = DISP
      mode: OUTPUT
    restore_mode: ALWAYS_ON

sensor:
  - platform: waveshare_io_ch32v003
    id: battery_voltage
    name: "Battery Voltage"
    waveshare_io_ch32v003_id: waveshare_io_hub
    reference_voltage: 9.9
    unit_of_measurement: "V"
    accuracy_decimals: 2
    device_class: voltage
    state_class: measurement
    update_interval: 60s

  - platform: wifi_signal
    name: "WiFi Signal"
    update_interval: 60s

  - platform: uptime
    name: "Uptime"

text_sensor:
  - platform: wifi_info
    ip_address:
      name: "IP Address"
    ssid:
      name: "Connected SSID"

button:
  - platform: restart
    name: "Restart"

  - platform: safe_mode
    name: "Safe Mode Boot"

  - platform: factory_reset
    name: "Factory Reset"
    disabled_by_default: true

i2s_audio:
  - id: i2s_shared
    i2s_lrclk_pin: GPIO16
    i2s_bclk_pin: GPIO44
    i2s_mclk_pin: GPIO6

audio_dac:
  - platform: es8311
    id: es8311_dac
    bits_per_sample: 16bit
    sample_rate: 44100

audio_adc:
  - platform: es7210
    id: es7210_adc
    bits_per_sample: 16bit
    sample_rate: 44100
    mic_gain: 24dB

speaker:
  - platform: i2s_audio
    id: i2s_audio_speaker
    i2s_audio_id: i2s_shared
    i2s_dout_pin: GPIO15
    dac_type: external
    audio_dac: es8311_dac
    channel: mono
    sample_rate: 44100
    bits_per_sample: 16bit
    timeout: never

  - platform: resampler
    id: announcement_speaker
    output_speaker: i2s_audio_speaker

media_player:
  - platform: speaker
    name: "Display Speaker"
    id: media_player_main
    announcement_pipeline:
      speaker: announcement_speaker
      format: FLAC
      sample_rate: 44100
      num_channels: 1
    on_play:
      then:
        - switch.turn_on: pa_ctrl
    on_idle:
      then:
        - switch.turn_off: pa_ctrl

microphone:
  - platform: i2s_audio
    id: va_mic
    i2s_audio_id: i2s_shared
    i2s_din_pin: GPIO43
    adc_type: external
    sample_rate: 16000
    bits_per_sample: 16bit

lvgl:
  displays:
    - lcd_display
  touchscreens:
    - touch_panel

  log_level: WARN
  color_depth: 16

  on_idle:
    timeout: 60s
    then:
      - globals.set:
          id: screen_on
          value: "false"
      - light.turn_off:
          id: backlight
      - switch.turn_off: disp_enable
      - lvgl.pause:

  pages:
    - id: page_main
      bg_color: 0x111318
      bg_opa: COVER
      widgets:
        - label:
            x: 340
            y: 220
            text: "Hello World"
            text_align: CENTER
            text_font: MONTSERRAT_24
            text_color: 0xFFFFFF
